Description
- Overview
- Features
- Technical Specifications
Overview
Opening its doors to all DJs, the ONE is a complete digital DJ solution built with legendary RANE quality. Showcasing its classic DNA, the ONE continues RANE's commitment to the art of DJing with motorized 7" platters, customizable torque, performance pads, 6 FX buttons, 3-band EQs, main/booth XLR outputs, and more. Featuring the latest MAG-FOUR fader, loop section, and in/out controls, the RANE ONE provides DJs with the ultimate control.
Features
- 7.2-inch Motorized Platters with Quick Release Acrylic Disks.
- Trusted RANE Build Quality and Feel.
- Instant Access Software FX with 2 Metal FX Paddles.
- Ultra-light MAG FOUR Crossfader.
- High/Low-pass Filter & 3 Band EQ.
- Dedicated Loop Controls.
- Independent Multi-Mode Performance Pads Including Serato.
- Scratch Banks.
- Turntable Style Start/Stop.
- XLR Main & Booth Outputs.
- (2) Line/Phono Inputs.
- (2) TRS/XLR Microphone Inputs.
- (2) USB Computer Connections.
- Portable DJ Controller (24lbs / 10kg.)
- Serato DJ Pro Included (paid upgrade to Serato DVS.)
Technical Specifications
| Digital Audio | |
|---|---|
| Converters | Cirrus Logic, 24-bit PCM, 48kH |
| Digital Signal Processing | 32-bit, Floating Pont, Double precision |
| Dynamic Range (A-weighted, unity gain) |
ADC: 113dB DAC: 113dB CD Input to Analog Output: 110dB CD Input to USB Output: 113dB USB Input to Analog Output: 113dB |
| Inputs | |
| Microphone 1/2 (Combo XLR/1/4" [6.35mm] TRS, Mic/Line switchable) |
Analog Gain: 25dB Maximum Input: 110mV Gain Trim: Off to +26dB (unity at center) Tone Control: 2-band |
| Aux Input (RCA stereo pair) |
Maximum Input: 4Vrms Dynamic Range (A-weighted): 114dB Gain Trim: Off to +12dB Tone Control: 2-band |
| CD/Phono Inputs 1/2 (RCA stereo pairs, switchable) |
CD: Line Maximum Input: 4Vrms Gain Trim: Off to +12dB Tone Control: 3-band, full-cut to +10dB THD+N (20kHz BW @ 1kHz): 0.004% Phono: RIAA RIAA Curve:+/-0.25dB Gain (@ 1kHz): 31.5dB Maximum Input (@ 1kHz): 106mV Dynamic Range (A-weighted): 102dB |
| Outputs | |
| Main Outputs (XLR) | Gain Trim: Off to 0dB Maximum Output: 8Vrms THD+N (20kHz BW @ 1kHz): 0.004% Frequency Response: Flat |
| Booth Outputs (XLR) | Gain Trim: Off to 0dB Maximum Output: 8Vrms THD+N (20kHz BW @ 1kHz): 0.004% Frequency Response: Flat |
| Master Outputs (RCA stereo pair) |
Maximum Output: 4Vrms THD+N (20kHz BW @ 1kHz): 0.004% Frequency Response: Flat |
| Headphone Outputs (1/4"/6.35mm and 1/8"/3.5mm TRS) |
Maximum Output Voltage: 4Vrms (no load) Output Power: 50mW (50 ohms) Dynamic Range (A-weighted): 108dB |
| General | |
| Pads | (16) velocity-sensitive multi-color back-lit pads (8 per deck, 8 modes each) |
| Faders | (1) MAG FOUR tension-adjustable crossfader with independent Contour and Reverse controls (2) Standard channel faders with shared Contour and Reverse controls |
| Connectors | (2) XLR outputs (Main) (2) XLR outputs (Booth) (1) RCA stereo output pair (Master) (2) XLR / 1/4" (6.35mm) TRS inputs (Mic 1–2) (2) RCA stereo input pairs (Deck 1–2) (1) RCA stereo input pair (Aux) (1) 1/4" (6.35mm) TRS output (Headphones) (1) 1/8" (3.5mm) TRS output (Headphones) (2) USB Type-B ports (1) IEC power cable input |
| Power | Connection: IEC Voltage: 100–240V, 50/60Hz Consumption: 50W |
| Dimensions (width x depth x height) |
26.5" x 13.6" x 4.9" 674 x 345 x 124.3mm |
| Weight (including platters) |
23.55 lbs. 10.68kg |
