The Compact Mixing System DYNACORD CMS 600-3 is a professional mixer offering an optimized all-in-one solution for basically any application. The CMS console is quickly set up. Complicated rack configuration and interference-prone wiring of several single components cease to apply. The mixer’s ergonomic console shape and clearly structured controls provide perfect overview for instant access at all times. Also during the transport you will quickly learn to appreciate the CMS’s superiority: compact dimensions and a very low weight. However, if you would rather like to install your CMS in a 19" rack shelf, no problem. The only thing you have to do is to replace the plastic side panels by a pair of metal rack mount ears. Through its multiple functions, its high dynamic capacity, and extremely low-noise design in combination with its 24-bit Dual-Stereo effect unit and the USB 2.0 DIGITAL AUDIO INTERFACE, the CMS is best equipped for universal use.
- 4 Mic/Line
- 2 Mic/Stereo USB (Super-Channels)
- 2 Stereo-Line
- All Channels with 3-Band EQ with Hi, Mid & Low
- Use of premium components (Faders and potentiometers from ALPS)
- Two editable digital effects units with 100 presets and 20 user memories
- Professional 4 IN / 4 Out USB Audio interface for connection to a PC or Mac
- Monitor Sends (pre-fader)
- Mic Inputs 1-6 have a gain control and switchable phantom power
- Channels 9/10 and 11/12 have a trim control
- Channels 1-4 with switchable 80 Hz LowCut Filter
- Intuitively easy to use mixer
- FX send for each channels are post fader, Aux Sends (globally switchable Pre- or Post Fader)
- Stereo Master Equalizer Large, high-contrast OLED display
- Master Fader L/R and one FX1, FX2, Aux and monitor return
- All channels with balance/pan control, Mute- and PFL Control and Volume fader with peak and signal indicator
| Auxiliarys (AUX, MON) | Pre/Post switchable, Pre |
| MIC GAIN (LINE -20 dB) | +10 to +60 dB |
| TRIM LINE/CD (Stereo) | -10 to +20 dB |
| THD, at 1 kHz, MBW = 80 kHz | |
| MIC input to Master A L/R outputs, +16 dBu, typical | < 0.005% |
| Frequency Response, -3 dB, ref. 1 kHz | |
| Any input to any Mixer output | 15 Hz to 70 kHz |
| Crosstalk, 1 kHz | |
| Channel to Channel | < -80 dB |
| Mute & Standby switch attenuation | > 100 dB |
| Fader & FX/AUX/MON-Send attenuation | > 85 dB |
| CMRR, MIC input, 1 kHz | > 80 dB |
| Input Sensitivity, all level controls in max. position | |
| MIC | -74 dBu (155 µV) |
| LINE (Mono) | -54 dBu (1.55 mV) |
| LINE (Stereo) | -34 dBu (15.5 mV) |
| CD (Stereo) | -34 dBu (15.5 mV) |
| Maximum Level, mixing desk | |
| MIC inputs | +12 dBu |
| Mono Line inputs | +31 dBu |
| Stereo Line inputs | +30 dBu |
| All other inputs | +22 dBu |
| All other outputs | +22 dBu |
| Input Impedances | |
| MIC | 2 ㏀ |
| CD In | 10 ㏀ |
| All other inputs | > 15 ㏀ |
| Output Impedances | |
| Phones | 47 Ω |
| All other outputs | 75 Ω (unbalanced), 150 Ω (balanced) |
| Equivalent Input Noise, MIC input, A-weighted, 150 ohms | -130 dBu |
| Noise, Channel inputs to Master A L/R outputs, A-weighted | |
| Master fader down | -100 dBu |
| Master fader 0 dB, Channel fader down | -92 dBu |
| Master fader 0 dB, Channel fader 0 dB, Channel gain unity | -82 dBu |
| Equalization | |
| LO Shelving | ±15 dB / 60 Hz |
| MID Peaking | ±12 dB / 2.4 kHz |
| HI Shelving | ±15 dB / 12 kHz |
| Master EQ 9-band (63, 125, 250, 500, 1k, 2k, 4k, 6.3k, 12kHz) | ±10 dB / Q = 1.5 to 2.5 |
| Filter | |
| LO-CUT, mono inputs | f = 80 Hz, 18 dB/oct. |
| Filter | |
| LO-CUT, mono inputs | f = 80 Hz, 18 dB/oct. |
| Display | 128 x 64 pixels, OLED |
| Effects | |
| Type | Dual stereo 24/48-bit multi effects processors |
| Effects presets | 100 Factory + 20 User, Tap-Delay |
| Remote control | Footswitch, MIDI |
| Digital Audio Interface | |
| Channels | 4 In / 4 Out |
| AD/DA Conversion | 24-bit |
| Sampling Rate | 44.1 / 48 / 88.2 / 96 kHz |
| PC Interface | USB2.0, Female Type B |
| Supported OS | See documentation |
| MIDI Interface | 5-pin DIN connector, In / Out |
| Protection | |
| Mixer Outputs (Relay controlled) | AUX, MON, MASTER A L/R |
| Switching Mode Power Supply (µC controlled) | Mains Over/Undervoltage |
| Phantom Power, switchable | 48 V DC |
| Power Requirements (SMPS with auto range mains input) | 100 V to 240 V AC, 50 Hz to 60 Hz |
| Power Consumption, at 1/8 maximum output power, 4 Ω | 35 W |
| Safety Class | I |
| Ambient Temperature Limits | +5 °C to +40 °C (40 °F to 105 °F) |
| Dimensions (W x H x D), mm | 416.9 x 108.6 x 347.8 Rack-mount (7.5 HE): 483.0 x 99.1 x 332.6 |
| Weight | |
| Net Weight | 5.8 kg |
| Shipping Weight | 7.8 kg |
| Warranty | 36 months |
